VV 25Solenoid-operated valves

Overview

  • high operating cycles
  • significantly better long term tightness even after long operating time
  • easy to clean
  • versatile connection alternatives via small flange or hose nozzle
  • low leakage rate
Cat. No.
20674105
Upon Request $999,999.99
Add to Compare list
VV 25 Solenoid-operated valves

By submitting the contact form, you agree to the processing of your data for the purpose of answering your request. Further information and information on revocation and objection can be found in our privacy statement.

Anti-Robot Verification
FriendlyCaptcha ⇗

Inquire
Add to Compare list
main product photo

Solenoid-operated valves in action

In-line isolation valve VV 25, 230 V / 50 Hz, KF DN 25

These straight-through valves with electromagnetic (solenoid) drive are used for operating cycles with short intervals and, therefore, are often used as vacuum control valves. The straightforward design provides a valve with low leakage rate.

für Zoom klicken

Technical data and graphs

Upper ambient temperature (operation) 50 °C
Lower ambient temperature (operation) 0 °C
Max. gas temperature 80 °C
Flange connection small flange KF DN 25
Operation Solenoid 230 V/~ 50 Hz
Leakage rate 1 x 10-4 mbar l/s
Max. switching frequency 120 pro Min.
Fitting length between flanges 100 mm

Downloads

In-line isolation valve VV 25,230 V / 50 Hz, KF DN 25
VV 25
Solenoid-operated valves
Manual accessories
Manual PDF 1.4 MB 1.2 MB
Download Download
